Value-stream mapping: definitions and examples

How do certain processes help you create value and meet customer requirements? Which activities add no value at all? Value-stream mapping can provide precise answers to these questions.

The aim of lean production in general and the continuous improvement process (CIP) in particular is to reduce throughput times. Doing so usually has a positive impact on productivity, since there is a close correlation between throughput times and productivity rates. However certain “opposing forces” can thwart attempts to achieve this aim. These are the 3Ms of lean production – so called because they all begin with the letter “M” – namely Muda (waste), Mura (imbalance) and Muri (overloading). Taking Muda – the best-known and impactful of the three – as an example, it is easy to highlight the kinds of things that get in the way of efforts to reduce throughput times. In the context of lean production, people always use the term Muda (waste) to refer to things that do not create value. Lean production focuses on seven types of waste (seven Muda) – these include activities such as overproduction and excessive movement of materials. However, how can you find out which activities in which process are not creating value in your own specific production operations? In lean production and lean management, this is precisely where value-stream mapping comes into play. This method is particularly used within the context of Six Sigma.

Definition of value-stream mapping (VSM)

So what exactly is value-stream mapping? Let’s start with the value stream itself. This comprises all the processes that are needed to manufacture and supply a product. Value-stream mapping offers a way of analyzing this value stream, providing a clear picture of the current state of the business processes. The various process steps are observed and timed, and the results are used to visualize material and information flows in a flow chart (see diagram further down). In general, value-stream mapping boasts certain characteristics and benefits:

  • Mapping, drawing and creating material and information flows
  • Reducing throughput times using a standardized, structured method for teams
  • Having a basis for dialogue (rather than discussion) makes team work easier
  • Providing a basis for optimizing processes and helping avoid/reduce waste

Once value-stream mapping has been completed, the next stage is value-stream design. This involves developing the target state of processes and planning the relevant improvements. A post dedicated to value-stream design will appear on the item blog soon. If you would like to find out about both methods in more detail, you’ll find what you’re looking for in the item Academy – the free item training platform that offers a wide range of content, including well-constructed courses on these particular topics. All you need to gain direct access to the “value-stream mapping” and “value-stream design” online training units is an item user account.

Value-stream mapping – how to go about it

The first step in value-stream mapping involves forming product groups. A product group is a collection of products that undergo similar process steps. The products and associated production steps are therefore set out in a matrix (see diagram). Take a tour through the manufacturing plant, noting down all the production steps for each product and each version of every product. Versions that have manufacturing steps in common are gathered together in one product group.

Value-stream mapping then needs to be carried out separately for each and every product group. If it isn’t possible to collect several products together into one product group, you end up with many product groups containing only one product. Then you need to carry out value-stream mapping for every single product. The disadvantage of this is that the results are less meaningful and less transparent. The diagram below illustrates the formation of product groups based on three different products.

Item méxico
Example of a product matrix created as part of value-stream mapping. Three different products are documented. Due to the three matches, type A and type C can form one product group. Value-stream mapping is carried out separately for type B.

Calculating the customer takt time and visualizing the value stream (with an example)

Once the product groups have been formed, the next step is to visualise the current situation in the form of a flow chart or value-stream diagram. This calls for precise knowledge of the customer’s requirements and is where calculation of the customer takt time comes into play. Customer takt time is the average (production) time after which the customer takes delivery of one more product. Later on, at the value-stream design stage, you can use this customer takt time to synchronize the production rate with the sales rate. This ensures your production is in line with customer requirements.

In the actual value-stream diagram, special symbols are used for basic information, material flow and information flow. You can find out exactly what these symbols mean in the free courses available in the item Academy – including tasks to test your knowledge and clearly presented PDFs that you can print out and pass on to others. The structure of value-stream diagrams is always the same. The customer (top right-hand corner) is always the starting point. The mapping process then proceeds upstream through production and back to the supplier to depict the entire value stream. Once completed, the value-stream diagram shows exactly where there is potential for improvement in the value stream – this might be in relation to throughput time or stock levels, for example. You can also use the diagram to identify any scope for synchronising worksteps. Below is an example of what the value-stream mapping outcome or value-stream diagram might look like.

Diagrama
This example of a value-stream diagram maps out the production of a threaded cylinder. Material movements are visualized by arrows. The words “customer” and “supplier” are inside the symbol for external sources.

Making targeted improvements to processes – even more lean production know-how
